Industrial Welded MeshSeriesModular Assembly SystemGroupPanels and Attachment FittingsMaterialWelded wireSurface TreatmentSprayColorBlackProduct IntroductionSteel meshes have good stability and inherent rigidity. Even light structure is qualified as a frame.The wires are welded together at each cross-over point to avoid becoming out of shape.Welded mesh surface is powder-coated or painted, for the purposes of increasing resistance to corrosion or identification.Customizing the Exact Size of Industrial Welded MeshThe maximum effective size of the mesh is 1700 x 1200 mm. If a larger area is needed, we suggest adding several cross-beams for mesh installation.L (length of mesh in the frame) = inside frame length 10mm; W (width of mesh in the frame) = inside frame width 10mm.Notification on cutting to size service: considering the behavior of the material during the cut, the cut-off tolerances are in DIN ISO 2768 tolerance class c.Related Popular ProductsWire mesh buckle: 2-3 blocks per meter can optimize the stability of mesh in the frame (the optimum distance between mounting blocks is 300mm).Anchor joint: for better installation adaptability between mesh and frame, we recommend an anchor joint as the connector for the profiles.Strut profile PG20-PG60: the welding mesh can adapt to all the profile groups we are offering with compatible mesh blocks.
